Product Description
ELP 2mp wide angle high speed night vision ir infrared usb camera with box housing mini UVC usb2.0 industrial CCTV webcam for computer
ELP-USBFHD05MT-KL156IR:
This model is a main member of ELP’s USB camera family. It’s a 2MP, night vision, high speed, wide angle, UVC-compliant, USB 2.0 camera. This USB camera is based on the 1/2.7” CMOS OV2710 image sensor. No longer be anxious about installing the driver! The native UVC drivers of Windows, Linux, and Mac shall be compatible with this camera so that it does not require extra drivers to be installed. This small-sized USB cam can also be used as a lightburn cam, which can be used to capture images of the workpiece and display them in the lightburn software. This is particularly useful for working with irregularly shaped workpieces or for engraving on objects that do not have a flat surface.
wide angle fisheye lens, FOV is about 166degree, Mjpeg/YUY2 optional, UVC for use in windows, linux, mac, raspberry pi, linux, android system
Parameter:
Model: ELP-USBFHD05MT-KL156IRSensor:1/2.7″ CMOS OV2710Lens: wide angle fisheye lensViewing Angle: 166degree2.0megapixel: 1920(H)x1080(V)pixelsSupport free driver: USB Video Class(UVC)Mini Illumination: 0.05LuxAuto exposure AEC: Support Auto white blanceFrame rate: MJPEG 30fps@1920 (H) x1080 (V) MJPEG 60fps@1280 (H) x 720 (V) MJPEG 100fps@640 (H) x 480 (V)Adjustable parameters:Brightness/Contrast/Color saturation /Definition/Gamma/WBSupport OS:”WinXP/Vista/WIN7/WIN8/Linux with UVC Mac-OS X 10.4.8 or later/Wince with UVC/Android 4.0 or above”
High Frame Rate USB Camera can drive 30fps@1080p, 60fps@720p, 100fps@VGA
Fast frame for high speed moving objects capturing Performance:
1920 (H) x 1080 (V) pixels MJPEG 30fps YUY2 6fps1280 (H) x 1024 (V) pixels MJPEG 30fps YUY2 6fps1280 (H) x 720 (V) pixels MJPEG 60fps YUY2 9fps1024 (H) x 768 (V) pixels MJPEG 30fps YUY2 9fps800 (H) x 600 (V) pixels MJPEG 60fps YUY2 21fps640 (H) x 480 (V) pixels MJPEG 100fps YUY2 30fps
General Software for USB Camera OPENCV,Blue iris Amcap,Webcam Viewer V4L2 video for LINUX Facetime,Quick Time ContaCam,Zoom Motion Eye OS Camerafi,iSPY USB Camera APP
2MP Full HD 1080P High Pixels for Shar Clear image
Max Resolution:
1920(H)*1080(V)
Plug and play,free driver, UVC compliant, mini light weight, compact lightburn laser day night vision usb camera for all kinds of machine vision
Day/Night Vision:
IR-CUT Filter switched in and out automatically based on light condition (only visible light during the daylight and infrared sensitivity during the night with 850 IR LEDs on)
Wide Angle Fisheye Lens:
Wider Angle of View:
Mini wide angle USB camera with fisheye lens, FOV is about 166degree.
Plug and Play/Free Driver
UVC-compliant, just connect the camera to PC, laptop, Android device or Raspberry Pi with the USB cable without extra drivers to be installed.
Auto IR infrared night vision USB camera, support different operating systems, different preview softwares
Applications:
home secutiry systemparking lot managementcar truck school bus interior monitoringindustrial machine vision.Dashcambaby dog pet cameravideo conferencehigh speed video shooting deviceobserving gold
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Customer Reviews
3.9 out of 5 stars
21
3.2 out of 5 stars
26
3.7 out of 5 stars
44
3.7 out of 5 stars
191
3.4 out of 5 stars
37
4.1 out of 5 stars
58
Price
$58.99$58.99 $56.99$56.99
— $40.99$40.99 $49.99$49.99 $67.99$67.99
Max Resolution
2.0Megapixel 1080P 2.0Megapixel 1080P 2.0Megapixel 1080P 1.0Megapixel 720P 2.0Megapixel 1080P 2.0Megapixel 1080P
Image Sensor
1/2.7″ CMOS OV2710 1/2.7″ CMOS OV2710 1/2.7″ CMOS OV2710 1/4″ CMOS OV9712 1/2.7″ CMOS OV2710 1/2.9″ IMX323
Lens
Wide angle fisheye lens 3.6mm lens 170degree fisheye lens 3.6mm Lens 3.6mm Lens 3.6mm Lens
Night Vision
✓
✓
✓
✓
✓
✓
H.264
NO NO NO NO NO
✓
USB Cable
3 Meters USB Cable 3 Meters USB Cable 3 Meters USB Cable 5 Meters USB Cable 5 Meters USB Cable 5 Meters USB Cable
Max Frame
480P@100fps 480P@100fps 480P@100fps 720P@30fps 480P@100fps 1080P@30fps
Support OTG
✓
✓
✓
✓
✓
✓
Plug and Play
✓
✓
✓
✓
✓
✓
Support OS
WinXP/Vista/WIN7/WIN8/Linux with UVC/Mac-OS X 10.4.8 or later/Wince with UVC/Android 4.0 or above WinXP/Vista/WIN7/WIN8/Linux with UVC/Mac-OS X 10.4.8 or later/Wince with UVC/Android 4.0 or above WinXP/Vista/WIN7/WIN8/Linux with UVC/Mac-OS X 10.4.8 or later/Wince with UVC/Android 4.0 or above WinXP/Vista/WIN7/WIN8/Linux with UVC/Mac-OS X 10.4.8 or later/Wince with UVC/Android 4.0 or above WinXP/Vista/WIN7/WIN8/Linux with UVC/Mac-OS X 10.4.8 or later/Wince with UVC/Android 4.0 or above WinXP/Vista/WIN7/WIN8/Linux with UVC/Mac-OS X 10.4.8 or later/Wince with UVC/Android 4.0 or above
With 10PCS IR LED for whole day and night image view
Equipped with Wide Angle 170degree fisheye lens
Adopt high quality 1/2.7″ cmos ov2710 image sensor
Can drive 30fps@1080P and 60fps@720p,120fps@480P
With mini black housing for any place to use
With 3Meters long USB Cables,plug and play
MJPEG/YUY2 Compression Format Optional
High Compatibility with Windows,Linux,Mac,Raspberry Pi,etc.
Can work with OPENCV,Contacam,Yawcam,iSpy,Motion Eye OS,AMCAP,Webcam Viewer,IP Camera Viewer,Zone Minder,V4L2 video for Linux,Camera fi,VLC Player,USB Camera APP,Photo Booth,Facetime,Zoom,Quick Time.
Used for all kinds of machine as below: a home surveillance system,wildlife photography,dash cam,baby camera,machinery equipment,all-in-one machine,POS equipment,STB,smart box TV BOX,advisement player,LED display,automatic vending machine,notebook,video door phone,MID,Tablet external,evaluator,Medical Equipment,on-the-spot law enforcement,etc.
